Form Factor
M.2 2280
-
Interface
PCIe Gen3x4
-
Performance
512GB - sequential read up to 3500MB/s, write up to 2400MB/s
IOPS: up to 200/256K
1TB - sequential read up to 3500MB/s, write up to 3000MBs
IOPS: up to 300/256K
2TB - sequential read up to 3500MB/s, write up to 3000MBs
IOPS: up to 300/256K
-
Operating Temperature
0°C to 70°C (32°F to 158°F)
-
Storage Temperature
-40°C to 85°C (-40°F to 185°F)
-
Dimension (L x W x H)
80 mm x 22 mm x 2.25 mm / 3.15” x 0.87” x 0.09”
-
Weight
9g
-
Warranty
5 year limited warranty
-
Shock Resistant
1500 G, duration 0.5ms, Half Sine Wave
-
Vibration Resistant
10~2000Hz, 1.5mm, 20 G, 1 Oct/min, 30min/axis(X,Y,Z)
-
TBW
2TB:1000, 1TB: 500TB, 512GB: 250TB, 256GB: 125TB
-
DWPD
1TB: 0.44, 512GB: 0.44, 256GB: 0.44
-
NAND flash
3D TLC
-
MTBF
1,500,000 Hours
1 Up to 3500MB/s read transfer, write transfer speeds lower. Speeds based on internal testing. Actual performance may vary.
2 Shock resistant (1500G, duration 0.5ms, Half Sine Wave) and vibration resistant (10~2000Hz, 1.5mm, 20G, 1 Oct/min, 30min/axis(X,Y,Z)). Based on internal testing. Actual performance may vary.
3 Comparison based on internal testing. Actual performance may vary.
[Note]:
Security safeguards, by their nature, are capable of circumvention. Lexar does not guarantee data will be 100% secure from unauthorized access, alteration, or destruction.
Actual usable memory capacity may vary. 1GB equals 1 billion bytes.
Product appearance, performance, software offerings, and packaging may vary depending on ship date and available inventory.
Lexar is not liable for any loss of data or images.
